Cell? Pack? Battery and Vehicle Optimization Are Becoming One

EV manufacturers frequently advertise “cell-to-pack,” “cell-to-body,” and other battery architectures as major innovations. Yet many readers are left wondering: What exactly is a cell? What is a pack? And why does it matter?

The distinction is much more than terminology. It affects vehicle cost, weight, range, charging performance, and ultimately profitability. To understand why these architectural innovations matter, we first need to understand the difference between a cell and a battery pack.

A battery is simply a device that stores electrical energy. It could be a non-rechargeable AA battery in your flashlight, the rechargeable battery in your smartphone, or the battery that powers an electric vehicle.

Batteries are built using different chemistries depending on the application. Lead-acid batteries continue to power the 12-volt electrical systems in most vehicles. The battery that propels an EV, however, is almost always based on lithium-ion technology. The following focuses solely on lithium-ion batteries.

There is an inherent system hierarchy:

• A cell is the basic energy-storage unit.
• A pack consists of hundreds or thousands of cells electrically connected together.
• The vehicle is powered by one battery pack – or multiple packs in trucks or energy storage systems (ESS).

Why Can’t We Just Make One Giant Cell?

Manufacturing very large lithium-ion cells is difficult because stresses, heat, and manufacturing tolerances become increasingly difficult to control. As a result, individual cells remain relatively modest in size.

A single lithium-ion cell is sufficient to power a smartphone. A laptop requires several cells connected together into a battery pack. An electric vehicle requires hundreds, or in some cases thousands, of cells assembled into one very large battery pack.

Early Tesla Model S and Model 3 vehicles used thousands of cylindrical cells similar in size to those commonly found in older laptop battery packs. Tesla later transitioned from the smaller 18650 cell to the larger 2170 cell, allowing each cell to store more energy. As a result, the number of cells in a Model 3 fell from more than 8,000 to roughly 4,400.

Every cell in a pack must be electrically connected to the rest of the cells, mechanically secured, monitored, cooled, and protected. Reducing the number of cells eliminates hundreds of welds, electrical connections, sensing points, and assembly operations. The result is a battery pack that is simpler to manufacture, lighter, less expensive, and more reliable.

The Engineering Reality of the Battery Pack

Up to this point, the distinction between a cell and a pack may seem largely semantic. After all, a pack is simply many cells connected together. But in an EV, nothing could be further from the truth. Once hundreds of cells are assembled into a battery pack the size of a vehicle floor, the engineering challenges change dramatically. The battery pack becomes one of the most complex subsystems in the vehicle.

A battery pack must provide mechanical protection during crashes, distribute electrical power safely, maintain an appropriate temperature window, monitor the health of every cell, prevent faults from propagating, survive years of vibration, and do all of this at the lowest possible cost and weight. Every one of these requirements competes with the others, making battery-pack design a complex engineering optimization problem.

To illustrate this complexity, I will focus on two engineering challenges: electrical power delivery and thermal management.

First is electrical connectivity. Peak currents in an EV pack routinely reach several hundred amperes. High voltages, low-resistance conductors, busbars, and electrical connections are essential to minimize power loss and unwanted heat generation.

The second challenge is thermal management. Consider DC fast charging. Modern chargers can deliver 300 to 400 kW of power. Although the electrical resistance of the cables, electronics, and battery is extremely small, it is not zero. At these power levels, that tiny resistance can generate 20 to 40 kW of heat inside the vehicle.

To put that into perspective, twenty kilowatts is enough to power about twenty microwave ovens simultaneously. Removing that heat quickly and uniformly is one of the defining engineering challenges of modern EV battery design.

The optimal operating range for most lithium-ion cells is approximately 25° C to 35° C, where battery longevity is greatest. Above about 55° C, degradation accelerates rapidly. As charging current increases, heat generation rises. If the cooling system cannot remove that heat fast enough, the battery management system reduces charging current to protect the cells. The driver experiences this as slower charging.

Cooling systems therefore become a careful engineering optimization. Too small, and charging performance suffers. Too large, and cost, weight, and vehicle range are negatively affected.

When an automaker announces a new cell-to-pack architecture, it does not necessarily mean someone has invented a better battery chemistry. More often, it means engineers have found a better way to integrate cells into the vehicle, reducing cost, weight, and complexity while improving performance. Some of today's innovation is happening in this integration layer.

For example, cell-to-body is one architecture receiving plenty of attention. Here, the battery pack itself becomes part of the vehicle’s structure. Rather than building a separate structural enclosure and then mounting it to the chassis, the cells are integrated directly into the vehicle chassis, allowing the battery to perform both structural and energy-storage functions. BYD’s Blade Battery illustrates this broader direction toward tighter structural integration, although manufacturers implement these architectures differently.

As pack architectures become simpler and more structurally integrated, software and battery intelligence become increasingly essential. Better models of cell and pack behavior allow engineers to reduce design margins, optimize cooling, improve fast charging, and extend battery life without adding hardware. In other words, software increasingly enables improvements that previously required material or mechanical redesign.

The industry often celebrates bigger batteries and faster chargers. Yet many of the most important advances now come from something less visible: better integration of the cell, the pack, and the vehicle into one optimized system.

As EV adoption accelerates, consumers demand better performance and lower prices, while investors demand stronger profitability. Innovation in pack architecture, rapid design iteration using advanced simulation tools, and the growing use of battery intelligence will increasingly separate tomorrow's market leaders from the rest. The next generation of electric vehicles will be defined not only by better cells, but by how effectively engineers optimize the battery and the vehicle as one integrated system.

‍
